Name: Novustechnicia
Brand: Novustechnicia

LABORATORY HOT PLATE (Round) NLH SERIES

Laboratory hot plates are available in different sizes and temperature ranges. It can be in both rectangular and round shapes with surface temperature range up to 350°C and optional 500°C. Heating surface is made of M.S, Stainless Steel or Cast Iron.

Temperature is controlled through energy regulator or digital PID controller which eﬃciently controls temperature and also displays set value and process value. Other cabinet is made of powder coated mild steel. These lab grade heating plates are light weight and durable.

Salient Features

Rugged In Design & Features
Complies with CE & ISO Standards
Light In Weight with Digital Controller to Increase the Eﬃciency
High Grade Stainless Steel used in production

Categories: All Products, Heating And Cooling, Strirrers/hot Plates

Description

Description

Model No.	NLH-02	NLH-04	NLH-06	NLH-08	NLH-10	NLH-12
Dimensions	250 x 300 mm/10*12"	250 x 400 mm/10*16"	300 x 455 mm/ 12*18"	455 x 455 mm/18*18"	455 x 600 mm/18*24"	600 x 600 mm/24*24"
Watt	1.2 kw	2.0 kw	1.5 kw	3.0 kw	3.0 kw	3.0 kw
Plate design						Rectangular and Round
Temperature						Up to 300°C
Heating plate surface						Stainless Steel 304 / Mild Steel / Cast Iron
Cabinet MOC						Powder coated MS
Controller						Thermostatic controller
Power supply						220 Volts 50Hz
Optional						Digital temperature controller, Temperature up to 500°C
